Overview

The LCC41 is an LTE Cat 1bis IoT module designed for M2M and IoT applications, compliant with 3GPP Release 14 standards. With its compact form factor and robust performance, the LCC41 supports data rates of up to 10 Mbps downlink and 5 Mbps uplink, and offers optional integrated GNSS for precise location tracking.

Equipped with a rich set of internet protocols, standard interfaces, and wide OS compatibility, including Windows, Linux, and Android, these modules enable seamless connectivity for asset management, telematics, payments, smart metering, and automation. LCC41 is the ideal LTE upgrade for transitioning from legacy 2G/3G networks to efficient, future-ready IoT solutions.

Key features

  • LTE Cat 1.bis
  • Compact Size
  • LGA Package
  • Embedded Abundant Protocols
  • Low Power Consumption
  • USB 2.0 High Speed Interface
  • Power Saving Mode
  • DFOTA Available

Specifications

Region India
Dimensions17.7 mm × 15.8 mm × 2.3  mm
Package  LGA
CPU ARM Cortex M3 processor @204MHz clock
Temperature  Operating Temperature : -35 °C to +75 °C
Extended Temperature : -40 °C to +85 °C
RAT  Cat 1.bis
Bands LTE FDD: 1, 3, 5, 8,
LTE TDD : 40, 41
Max. Data Rates DL 10 Mbps & UL 5 Mbps
3GPP Release 14
Interfaces GPIOs/Interrupts, USB2.0/USB BOOT, ADC, U(SIM): Support 1.8/3V – two sim support
UART/ DEBUG UART, SPI, RESET, PWRKEY, I2S Audio Interface
Low Power Modes PSM, DRX, eDRX
Protocols TCP, UDP, TLS, HTTP(S), MQTT(S), CoAP, LwM2M, FTP(S), DLMS/COSEM, NTP, NITZ,SSL
Other Features DFOTA, Wifi Scan
USIM DSDS, SSDS
