Intelligent Power Modules
Extensive lineup of configuration, packaging, and wattage options for various applications
Overview
The IPM modules are designed using IGBT technology to simplify system design, improve overall reliability, and enhance energy efficiency in power conversion and motor-drive systems.
LTSCT is also pioneering the development of ultra-efficient SiC-based Intelligent Power Modules (IPMs), integrating SiC MOSFETs, Isolated Gate Drivers, and Isolated Power Supplies into a single compact package. Built on proprietary advanced packaging technology, these IPMs offer:
- Exceptional system efficiency
- Significant reduction in system cost
- Minimised parasitics, enabling high-frequency operation
- Enhanced thermal management, ensuring long-term reliability and robustness
By simplifying system architecture and enabling compact, high-performance power conversion, LTSCT’s IPMs empower customers to meet the growing demands of renewable energy, EV infrastructure, industrial drives, and data centre power systems.
Key features
- Built-in protection circuit threshold adjustment and SW speed adjustment
- Easy replacement due to pin-compatibility
- Built-in bootstrap diode
- Overcurrent setting is set internally
Product line-up
Technical resources
| Part number | Product status | LTSCT package | Configuration | Blocking Voltage | Current Rating | Tjmax | Module Size | Qualification | Datasheet |
|---|---|---|---|---|---|---|---|---|---|
| LTD-2P100D160T1 | Active and Preferred | Type-D | 2-In-1 Diode Module | 1600V | 100A | 150°C | 93 × 26.7 × 29.3 mm | Industrial | Available |
| LTI-6I020E065D1 | Active and Preferred | Type-E | 6-In-1 IPM | 650V | 20A | 150°C | 70 × 49.5 × 18 mm | Industrial | Available |
| LTI-6I050E065D1 | Active and Preferred | Type-E | 6-In-1 IPM | 650V | 50A | 150°C | 70 × 49.5 × 18 mm | Industrial | Available |
| LTI-6I025C120C1 | Active and Preferred | Type-C | 6-In-1 IPM | 1200V | 25A | 150°C | 81.4 × 37.9 × 16 mm | Industrial | Available |
| LTI-6I035C120C1 | Active and Preferred | Type-C | 6-In-1 IPM | 1200V | 35A | 150°C | 81.4 × 37.9 × 16 mm | Industrial | Available |
| LTI-6I075A120A1 | Active and Preferred | Type-A | 6-In-1 IPM | 1200V | 75A | 175°C | 116 × 84 × 14 mm | Industrial | Available |
| LTI-6P035G125W1 | Active and Preferred | Type-G | Converter – Inverter PIM | 1250V | 35A | 175°C | 107.5 × 45 × 17 mm | Industrial | Available |
| LTI-6P050G125W1 | Active and Preferred | Type-G | Converter – Inverter PIM | 1250V | 50A | 175°C | 107.5 × 45 × 17 mm | Industrial | Available |
